Arched metal detector with integrated radiation monitoring system B2scan SD1000-RC-09

• LED indication of detected objects on the control unit display and side panels
• Adjustable number of detection zones: 6, 12, or 18 zones
• Audio and visual alarm with adjustable signal duration, volume, and melody
• Ensures high selectivity and operates in detection modes for mixed, ferrous, and non-ferrous metals
• Automatic compensation of external interference
• Protection against false alarms
• Two-level protection against unauthorized access: software protected by password, control unit housing lockable with key
• 72 preset selective detection programs, with ability to create custom programs
• Passage width: 760 mm, 820 mm, or 1000 mm
• Minimum distance between detectors: 0.3 m (without synchronization cable)
• Power and Ethernet cable entry options on the left, right, and top sides of the metal detector
• “Stop / Go” indicators on the front panel
• Dry contact outputs for connecting external equipment (turnstile, gate, camera, etc.)
• Passage and alarm counters
• Anti-passback mode
• Integrated uninterruptible power supply for autonomous operation — optional
• Computer control module: connection to PC via USB, Ethernet, or Bluetooth
• Mobile app for controlling the metal detector from a smartphone or tablet
• Data transmission over a local network using TCP/IP protocols
• Integration with technical monitoring and control systems via standardized data transmission protocols and XML-based metadata format

Specifications of the KRП-09 Radiation Detection Module

• LED indication of radioactive material detection on the control unit display
• Audio alarm upon detection of radioactive materials
• Gamma radiation energy detection range: 0.05 to 3.0 MeV
• False alarm rate: no more than 0.001%
• Continuous operation mode: 24/7
• Sensitivity variation due to temperature changes within operating range: no more than ±2%
• Sensitivity variation due to power supply voltage fluctuations within operating range: no more than ±2%
