Automatic detection and alarm of explosives and drugs
Advanced material classification: orange for organic, blue for metal and green for mixed material.
Technological peculiarities:
- High image quality with 40 AWG wire resolution and the penetrating power of steel 18 mm.
- The X-ray dose rate around the equipment is close to the natural background level, which corresponds to all applicable international health standards and occupational safety.
- Automatic detection of explosives /drugs.
- TIP (projection of the image of dangerous objects) is a very effective way to train operators and control their work.
- Functional stepwise, continuous and local scaling provides convenient and quick magnification of the resulting image.
- The resulting images can be saved in common formats (BMP, JPG, PNG) and transfer to an external USB drive.
- The ergonomic design of the keyboard and user interface ensures effective and professional work of X-ray television introscope.
- The modular design, combined with built-in diagnostics, ensures efficient maintenance of the equipment.
- Data transmission over a local network using the TCP / IP family of protocols.
- Information exchange with the system of collecting results of technical monitoring and control using a unified data transfer protocol and an XML-based metadata.
ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ
| General specifications | Operating characteristic | ||
|
Tunnel dimensions
|
505 mm (W) ×320 mm (H) |
Wire Resolution |
40 AWG / 0,0787 mm |
| Conveyor speed |
0,2 m/s |
Steel penetration |
18 mm |
|
Conveyor height |
695 mm |
X-ray dose during the inspection |
less than 2,5 mSv |
| Maximum load capacity | 100 kg with an even distribution |
Monitor |
LCD, 21.5 inches, high resolution 1920×1080 |
| Anode voltage |
100 kW |
||
| Image processing system | Health and safety | ||
|
Image processing functions |
Color / BW image, organic / inorganic removal, change in absorption level, super-enhancement, negative image, high / low penetration, pseudocolor, etc. |
X-ray dose rate |
Less than1mSv /h (5 cm from the body) meets all applicable international standards |
|
Material classification (by color) |
Organic: orange, inorganic: blue, mixtures and light metals: green |
Safety for photographic films |
Guaranteed for highly sensitive film up to ASA/ISO 1600 (33DIN) |
|
Scaling |
Selectable image scaling areas, magnification 1 ~ 64 times |
installation data |
|
| Image return | Viewing previous images |
Dimensions/weight |
1200 mm (L) × 728 mm(W) ×
1200 mm (H) / 300 kg |
| Memory capacity | Up to 100 000images | Storage temperature | -40°C~+60°C |
|
Additional functions |
Date / time display, baggage counter, transaction log, user management, System-on/X-ray-on timers / Power-on self-test, built-in diagnostics tools, bi-directional scanning, image recognition training | Operating temperature range |
0°C~+40°C |
|
Humidity |
5%~95% non-condensing | ||
|
Power supplies |
AC power
220В(-15%~+10%), 50 Hz / 60 Hz ± 3 Hz |
||
|
Power consumption |
0.5 kVA |
||
The equipment has passed compulsory and voluntary certification applicable on the Russian Federation territory. Technical parameters and complete set of goods are subject to change without notice.
